Aluminum Reinforced Tape, Aluminum Foil Duct Tape for HVAC, Exhaust Pipes

The FSK aluminum Tape is composed of aluminum foil, fiberglass mesh cloth (or kraft paper), and adhesive layer, and has a reinforced structure to enhance tensile strength and thermal insulation performance.

Place of Origin:

Jiangsu, China

Size:

50mm*20m or as your request

Color:

Silvery

Temperature Resistance:

-20 ºC to 120 ºC

Material:

Aluminum foil+fiberglass mesh or kraft paper+pressure-sensitive adhesive+release paper

Brand:

Jerrytape

Waterproof:

Waterproof

Model NO.:

AFT-FSK-001

Inquiry

Write a Review

Customized

Customization supported

Sample

Free Provided

Color

Silvery

Width

48mm,50mm,60mm,100mm or as You Need

Length

20m, 50m or as You Need

Application

Plastic, Metal, Wood, Glass, Ceramic

Production Capacity

20containers/Month

Origin

Jiangsu, China

Specification

50mm * 0.15mm * 20m or as your request

Feature

Strong viscosity, high temperature resistance, sealing, insulation, waterproofing, shielding, conductive.

Adhesive

Acrylic Acid

Thickness

0.025-0.07mm (aluminum layer) as You Need

Product Introduction

Composite layered design
Surface layer: Soft aluminum foil (usually 7 μ m thick), providing high reflectivity (≥ 95%) and metal barrier.
Middle layer: Glass fiber mesh reinforcement (such as 8 × 12/100mm three-dimensional mesh), significantly improving tensile strength and tear resistance.
Bottom layer: Kraft paper (about 25 grams) or flame-retardant paper, providing basic support and flame retardancy.
Adhesive layer: Acrylic pressure-sensitive adhesive (partially containing flame retardant), with high initial adhesion, weather resistance, and long-lasting bonding strength.
Substrate material
Use silicone isolation paper or white coated release paper to prevent adhesive layer adhesion and facilitate construction.

Core performance characteristics
1. Excellent high temperature resistance performance
2. Excellent tensile strength and tear resistance
3. Excellent heat reflection and insulation performance
4. Excellent sealing performance (waterproof, moisture-proof, and gas resistant)
5. Excellent fire resistance and flame retardancy
6. Good weather resistance and chemical resistance
7. Reliable insulation performance (electrical, thermal)
8. Stable size, not easily shrunk or deformed

Aluminum Reinforced Tape, Aluminum Foil Duct Tape for HVAC, Exhaust Pipes 12

Product advantages

Premium FSK Aluminum tape for HVAC Applications

FSK Aluminum tape boasts a 1.57 mil thick layer of aggressive adhesive for a formidable bond, complemented by a 3.35 mil removable paper release liner. The FSK hvac tape combination ensures easy application and strong adherence to a variety of surfaces.

Enhanced Composition for Superior Strength

Our aluminum foil tape features a 5.3 mil total thickness, Silver tape including a 3.74 mil layer of dead soft aluminum foil reinforced with a high-strength scrim, providing unparalleled durability and reliability.

High quality insulation sealing tape

Ideal for use as a closure system on fiberglass and mineral wool insulation systems with foil facing. The aluminum tape for ductwork excels in sealing seams and joints on aluminum-faced fiberglass duct board.

Exceptional Flexibility and Conformity

The hvac tape foil Designed to effortlessly conform to irregular and curved surfaces, the Aluminum tape's flexible nature ensures maximum adhesive contact for a secure and rapid bond to insulation surfaces.

application scenarios

FSK Aluminum tape(Reinforced aluminum foil tape) is a high-performance composite material specifically designed for insulation, sealing, and protective engineering. It combines the advantages of multiple materials and is widely used in fields such as construction, HVAC, and industrial packaging.
Building insulation engineering
External protective sealing of wall/roof/floor insulation layer, steel structure roof soundproof veneer.
Used for waterproof sealing of glass wool board and rock wool composite board joints to prevent thermal bridging effect.
HVAC
The joint fitting and water vapor sealing of the air duct system (glass wool board air duct, galvanized iron sheet air duct).
Repair of insulation nail punctures and wrapping of pipeline insulation sleeves (such as air conditioning refrigerant pipes).
Industrial protection
Export equipment with moisture-proof, anti mold, and anti-corrosion packaging; Insulation for automotive/ship pipelines.
Electronic component heat dissipation assistance (requires insulation layer).
Special purpose
Shielding electromagnetic interference (such as wrapping data cables, inner walls of chassis), and preventing radiation.
